The 767 and 777 are vastly different aircraft that are over 20 years apart in terms of development.  The 767 first flew in 1981 while the 777 first flew in 1994. The two programs though actually share much in common.  The 777 first grew out of a desire to grow the 767 and add additional range to it.  While the program eventually morphed into a completely separate airplane, there are still some similarities between the two airplanes.

For one, the 767 and 777 share the same radome cover.  They also share the same Section 41- the fuselage subassembly that encompasses the cockpit cab from the nose to just behind the windscreen. If you covered up the UPS markings and pitot tubes, you wouldn’t be able to tell if this was a 767 or 777 nose. Of course between the two the avionics package is vastly different and the location of the pitot tubes is also different. In the 777 development, using the 767 Section 41 saved development costs and a new round of bird strike testing wasn’t needed since it was already tested and cleared during the 767 development.

If you love this #avgeek tidbit of knowledge, be sure to follow our resident #avgeek expert, JP Santiago on Instagram: @SentinelChicken and on his Facebook page at: The Chicken Works.

In this day and age, its super common for airplane manufacturers to use very complex Computational Fluid Dynamics (CFD) software and Computer Aided Design to test and build airplane wings.  The new wings on airplanes like the 787 and Airbus A-350 are both relatively simple in structure and super efficient.  But these fancy tools didn’t really exist back in the late 1950s and early 1960s.

Back then the only tools they had were slide rules, blueprints and wind tunnels.  That fact makes the triple-slotted Krueger flaps on the Boeing 727 even more amazing.  These flaps allows short-field takeoffs and jet operations out of hot and high airfields like Mexico city and Chicago Midway.  In the video below, check out the amazing transformation of the wing on the aged but beautiful 727-200.  It’s an #avgeekery work of art.

This video and more beautiful #avgeek videos are available at airsidetv.com

November 16, 1982. That was the day Boeing nearly lost a 757 during the flight test program. It was during a flight into known icing conditions to test the 757’s deicing systems. Two inches of ice built up on the wings. At the time, Rolls Royce thought a flexible spinner hub on the fan would prevent ice formation instead of a traditional heated fan spinner which would be heavier. It didn’t work. Large chunks of ice from the spinners were ingested by the engines, damaging the fan blades to the point that the flight crew had to throttle to idle and coast back to Boeing Field- to descend into terrain around Seattle with insufficient engine power to go around left many shaken, from the flight crew, test engineers, and FAA reps onboard.

Rolls had to hurriedly design a traditionally heated spinner hub for the RB211 engines which met the icing criteria and testing. You can read a little bit more about this incident in a Seattle Times article about the 757 here: http://seattletimes.com/news/business/757/part05/
